WriteProtect™ – PORTABLE
Description
The WriteProtect™-PORTABLE supports PCIe, SATA and USB3.0 interfaces and features a fast Superspeed USB3.0 host connection. The WriteProtect™-PORTABLE provides digital forensic professionals with fast, secure, read-only write-blocking of PCIe M.2, SATA and USB3.0 suspect hard drives. Small in size but feature-packed, it is the ideal write-block solution for field acquisitions.
DESCRIPTION
The WriteProtect-Portable provides fast, secure, write-blocked access for PCIe M.2 NVMe, AHCI PCIe, mini-PCIe express cards, SATA, and USB 3.0 source drives. It features a high-speed USB 3.0 host connection and a browser-based interface for HPA/DCO management and software updates. The device is designed for portable forensic use and can also be deployed in a bay configuration for forensic workstation integration.
- Supports write-blocked access to PCIe, SATA, USB 3.0/2.0/1.1 devices
- Fast USB 3.0 host connection for high-speed operation
- Browser-based interface for drive management and updates
- Supports HPA/DCO detection and configuration
- Available in portable and workstation (bay) configurations
SPECS
- Power Requirements : 72 Watts
- Power Supply Voltage (DC IN) : +12VDC @ 6A
- Output Voltage (DC OUT) : +5VDC @ 2.5A, +12VDC @ 2.5A
- Net Weight : 0.8 lbs (0.36 kg)
- Dimensions : 7.0″ L × 4.3″ W × 2.0″ H (17.7 × 10.9 × 5.08 cm)
- Agency Approvals : RoHS Compliant
FEATURES
- Ultra-Fast USB 3.0 : High-speed USB 3.0 host connection for efficient forensic operations.
- Write-Blocking : Read-only, write-protected access for PCIe, SATA, and USB devices.
- PCIe Support : Supports M.2 NVMe, AHCI, SATA, PCIe, and mini-PCIe via optional adapter kit.
- Multi-Port Design : Includes SATA, USB 3.0, and PCIe write-protected source ports with Gigabit Ethernet connectivity.
- Drive Compatibility : Supports IDE, ZIF, mSATA, microSATA, eSATA, and flash media via adapters.
- Adapter Kit Support : Optional kit supports M.2 PCIe/NVMe/SATA and mini-PCIe drives.
- Browser-Based Interface : Manage operations, updates, and network settings via web interface.
- HPA/DCO Management : Detect and manage HPA/DCO via built-in interface.
- LED Indicators : 6 LEDs for power, activity, host, device, and HPA/DCO status.
- Portable Design : Lightweight (0.8 lbs) and compact for field use.
- Software Compatibility : Compatible with major forensic acquisition and analysis tools.
- Warranty : 1-year standard warranty with optional extensions available.
ACCESSORIES
- PCIe Adapter Kit : Supports M.2 PCIe, NVMe, SATA, mSATA, and mini-PCIe drives.
- mSATA to SATA Adapter : Enables cloning of mSATA drives.
- microSATA to SATA Adapter : Supports microSATA drive cloning.
- eSATA Cable : For connecting and cloning eSATA drives.
- U.2 NVMe to PCIe Adapter : Supports U.2 NVMe SSDs.
- Extended SATA Cable : 18-inch SATA connection cable.
- IDE to SATA Adapter : Supports 2.5″ and 3.5″ IDE/PATA drives.
- 1.8″ ZIF & IDE Adapter : Adapter pack for 1.8″ IDE/PATA drives.
- USB Flash Card Reader : Supports SD cards and CompactFlash media.
- USB to SATA Adapter : Converts USB 3.0 port for SATA drives.
- SATA/SAS Cable Set : Replacement data and power cables.
